300KW medium frequency induction heating equipment

2025.03.31

Energy-saving SD W-300KW medium frequency induction heating equipment is mainly for

1. Heating forging of round steel, square steel, bar and other workpieces with a diameter of 80mm or less ;

2. Quenching of gears with a diameter of about 750mm ;

3 , 900mm diameter sprocket quenching, single tooth quenchable modulus of about 50mm , diameter of about 300 shaft quenching, quenching uniform, good effect.

Equipment advantages

1 , IGBT inverter technology and series resonant circuit;

2 , the frequency range is wide, from 1KHz-8KHz , can be matched according to the heating depth of the specific heating workpiece , the adaptation range is large;

3 , using intelligent inverter control technology, all soft Next:

main feature:

1 , IGBT inverter technology and series resonant circuit;

2 , the frequency range is wide, from 1KHz-8KHz , can be matched according to the heating depth of the specific heating workpiece , the adaptation range is large;

3. Adopt intelligent inverter control technology, full soft switch precision control, high reliability of equipment operation and low maintenance rate;

4 , high efficiency and energy saving, 10%-30% energy saving than thyristor medium frequency , high power factor and power efficiency in full power range;

5 , 100% full load, 24 hours continuous working capacity;

6. Full display of frequency, power, voltage and current;

7. Simple operation, simple installation, connect three-phase 380V and cooling water.
